ART USBMix4

Input Connections XLR & ¼.-inch Balanced Combi-jack (CH 1 & CH2)
¼.-inch TRS Balanced (CH3 & CH4)
1/8-inch TRS Aux/MP3, 1/8-inch Headset Mic
Output Connections ¼.-inch TRS Balanced Main Mix Outputs
¼.-inch TRS Stereo Output & Monitor Outputs
1/8th-inch Headset Output
Signal to Noise Ratio >.90dB Typical (Ref 0dBu)
Maximum Input Level +8dBu (Mic), +16dBu (1/4-inch Input)
Maximum Output Level +15dBu Main Mix Outputs
Maximum Gain >.55dB (Mic), >.37dB (Instrument), 5dB (CH3 & CH4)
USB Computer Interface USB Class Compliant plug-and-play Mac / PC Interface
Power Via USB or 5VDC @ 500mA
Dimensions 1.75&Prime.H x 5.1&Prime.W x 7.5&Prime.D (45mm x 130mm x 191mm)
