Audient ORIA

Specificatii tehnice

Intrari microfon

• Gain: 60dB
• Nivel maxim de intrare: +18dBu
• Crosstalk: <105dB
• THD+N: 0.0015% / -96dB
• EIN: -129dB
• CMRR: -85dB
• SNR: 100dB
• Raspuns in frecventa: ±0.5dB 20Hz - 40kHz
• Impedanta de intrare: 1.5kΩ balansat

Intrari linie

• Gain: -10dB pana la +50dB
• Nivel maxim de intrare: +18dBu
• THD+N: 0.0015% / -96dB
• Impedanta de intrare: 4.7kΩ balansat

Intrare D.I / Instrument

• Gain: 60dB
• Nivel maxim de intrare: +18dBu
• THD+N: 0.16%
• SNR: 100dB
• Raspuns in frecventa: ±0.5dB 20Hz - 40kHz
• Impedanta de intrare: 370kΩ nebalansat

Iesiri linie

• Nivel de referinta: +18dBu
• THD+N: 0.0006%, -105dB
• Dynamic Range: 126.5dB
• Crosstalk: -123dB
• Raspuns in frecventa: ±0.3dB 10Hz - 40kHz
• Impedanta de iesire: <100Ω balansat

Iesiri pentru casti

• Nivel de referinta: +18dBu
• THD+N: 0.0007% (-103dB)
• Dynamic Range: 124dB
• Crosstalk: -115dB
• Raspuns in frecventa: ±0.25dB 10Hz - 40kHz
• Impedanta de iesire: <50Ω nebalansat
• Putere maxima @ 30Ω: 5.47V Peak, 3.87Vrms, 997mW
• Putere maxima @ 60Ω: 7.4V Peak, 5.29Vrms, 912mW
• Putere maxima @ 600Ω: 8.6V Peak, 6.09Vrms, 123mW

USB-C

• Conector: USB Type-C
• Cablu inclus: USB Type-C la USB Type-C
• Numar de canale de intrare: 34 (2 analogice, 16 digitale, 16 AOIP*)
• Numar de canale de iesire: 38 (20 iesiri linie, 2 iesiri casti stereo, 16 AES)
• Necesita card AOIP

Intrari digitale

• ADAT 16 canale: 44.1kHz - 48kHz
• ADAT 8 canale (SMUX): 88.2kHz - 96kHz

Iesiri digitale

• AES: 16 canale audio (8 fluxuri de date AES)
• Word Clock

Intrare si iesire Word Clock: 44.1kHz - 96kHz

Latenta DSP

• 44.1kHz – 6.5ms
• 48kHz – 6.3ms
• 88.2kHz – 5.5ms
• 96kHz – 5.4ms
• AOIP (Optional - Card Dante Expansion)
• Intrari AOIP: 16 (44.1kHz - 96kHz)

Alimentare

• Tensiune de intrare: 85 - 264V AC
• Frecventa de intrare: 47 - 63Hz

Cerinte minime de sistem

ORIA Desktop App

• macOS: 10.13.6 High Sierra
• Windows: 10

SoundID Reference

• macOS: 11 Big Sur
• Windows: 10
