The PT-D7700E series combines the latest
3-chip system based on DLP™ technology
with a new optical system developed using
our exclusive technology. We have dramatically
reduced the cabinet size, creating a unit
with only one-fifth the size of conventional
large-venue 3-chip DLP™ projectors. This feat
of design and technology achieved the world’s
lightest* 3-chip projector with DLP™ technology.
With a weight of 22.0 kg (48.5 pounds),
the PT-D7700E/E-K can go places other
bulky 3-chip projectors with DLP™ technology
have never gone before.
Specificatii tehnice
System: DLP™ projection system
Device: 0.95˝ (diagonal) DLP™ chip (x 3), 4:3
Pixels: 1,470,000 (1,400 x 1,050) x 3
Lamp: 300 W UHM™ lamp x 2 (BriteOptic™ Dual Lamp System)
Brightness: 7,000 lumens (dual lamp)
3,500 lumens (single lamp)
Contrast Ratio: 4,000:1 (full white/full black, with dynamic iris set to “3”)
Resolution: 1,400 x 1,050 pixels
Lens: Optional
Screen: 70˝– 600˝ diagonal
70˝– 300˝ diagonal, 4:3 aspect ratio with the ET-D75LE5
Video Signal: NTSC, PAL, SECAM, M-NTSC, PAL60, PAL-M, PAL-N
Terminals:
- VIDEO IN: BNC
- VIDEO OUT: BNC
- S-Video IN: Mini DIN 4-pin
- RGB1/YPBPR IN: BNC x 5
- RGB2 IN: D-sub HD 15-pin
- Optional board slot: x 1
- RS-232C/422 IN: D-sub 9-pin female
- RS-232C/422 OUT: D-sub 9-pin male
- REMOTE 1 IN: M3 jack
- REMOTE 1 OUT: M3 jack
- REMOTE 2 IN: D-sub 9-pin female (parallel)
Lens Shift: Powered; horizontal ±30%, vertical ±50%
Keystone Correction Range: ±40° with ET-D75LE2
±19° with ET-D75LE5
±28° with ET-D75LE6
Installation: Front/rear, ceiling/floor, (menu selection)
Powercord length: 2.5 m (8.2´)
Power supply: 220–240 V AC, 50/60 Hz
Power consumption: 800 W (800 VA) (15 W during standby mode with fan stopped)
Dimensions (W x H x D): 530 x 200 x 540 mm
(20-7/8˝ x 7-7/8˝ x 21-9/32˝) (without lens and lens hood)
Weight: Approx. 22.0 kg/48.5 lbs (without lens)
