Native Instruments - Audio 4 DJ

---

   Native Instruments presents the AUDIO 4 DJ, the compact audio interface for DJs who demand premium sound quality. With all the connections you need in one sturdy and portable design, this hardware is destined to be the centerpiece of your DJ set-up – at home and in the club. You can also record live sets and digitize your vinyl collection.

---



---

   Features:

---



---

   • Professional 24-bit/96 kHz audio interface with ultra-high quality Cirrus Logic® AD/DA converters

---

   • High-power 1/4" headphone output with dedicated level control

---

   • Four 9.7 dBu outputs (RCA)

---

   • Four 12 dBu inputs switchable between line and phono

---

   • Low latency ASIO™/Core Audio™/DirectSound™ driver

---

   • USB 2.0 bus powered

---

   • Eight status LEDs for instant visual monitoring of entire signal chain

---

   • Ultra-compact footprint

---

   • Built tough with sturdy metal enclosure and heavy-duty components

---



---

   Technical Data:

---



---

   System Requirements:

---

   • Windows®Windows® XP Pentium or Athlon 1.4 GHz, 512 MB RAM, USB 2.0 port, Service Pack 2

---

   • MAC OS® X 10.4, G4 1.4 GHz or Intel® Core™ Duo 1.66 GHz, 512 MB RAM, USB 2.0 port

---



---

   Dimensions:

---

   • 4"(101 mm) x 4.8" (121 mm) x 1.7"(42 mm)

---

   • Weight: 1.1lb (511 grams)

---



---

   Supported Drivers:

---

   • ASIO™, Core Audio™, DirectSound®

---



---

   Power Supply:

---

   • Power Supply Via USB 2.0 interface, 5V 500mA bus power. No additional power supply or battery is needed.

---



---

   • Audio Inputs (A/D)

---

   • Channels 4

---

   • Sample Rate 44.1, 48, 88.2, 96 kHz

---

   • Bit Resolution 16, 24-bit

---

   • Converter Cirrus Logic

---

   Line Inputs:

---

   • Input Impedance 1 MOhm

---

   • Full Scale Level + 12,5 dBu

---

   • SNR (weighted) 99,7 dBu

---

   • THD+N 0,019%

---

   • Frequency Response +/-1 dBu 10 Hz-40 kHz

---

   • Dynamic Range codec 105 dBu

---

   Phone Inputs:

---

   • Input Impedance 47 KOhm

---

   • Full Scale Level @ 1 kHz - 21,2 dBu

---

   • SNR (weighted) @ 1 kHz 87,2 dBu

---

   • THD+N @ 1KHz 0,09%

---

   • Frequency Response +/-1 dBu 10 Hz-40 kHz

---

   Audio Outputs (D/A):

---

   • Channels 4

---

   • Sample Rate 44.1, 48, 88.2, 96 kHz

---

   • Bit Resolution 16, 24-bit

---

   • Converter Cirrus Logic

---

   Line Outputs:

---

   • Output Impedance 100 Ohms

---

   • Maximum Output Level +9,6 dBu

---

   • SNR (weighted) 100 dBu

---

   • THD+N 0,006%

---

   • Frequency Response +/- 1 dBu 10 Hz-40 kHz

---

   • Dynamic Range codec 105 dBu

---

   Headphone Output:

---

   • Load Impedance 16 Ohms – 600 Ohms

---

   • Maximum Output Level (100 Ohm load) 1,55 V RMS (load 100Ohm), 3,1V RMS (no load)

---

   • SNR (weighted) 93 dBu

---

   • THD+N (100 Ohms) 0,016%

---

   • Frequency Response +/- 1 dBu 10 Hz-40 kHz
