Close the circle
The new Xciter lighting controller from Martin closes the circle on total performance control. It provides complete functionality to your fingertips, with instant pitch adjustment, freeze, flash, blackout, master fader and more. From the most personal show to mid-sized performances, the Xciter puts you in total control.
Live control
Let your impulses take over. Improvise and match the mood with instant pitch adjustment, freeze, flash, blackout, master fader and more. Xciter gives you unprecedented spontaneity with six general faders and two masters, six flash and four customised buttons. Every cue, every effect, every fixture for every beat, is now just a hand reach away.
The X FX
With Xciter, lighting and effect triggers are no longer confined to simple BPM’s. The Xciter sports leading edge technology that allows different fixtures to follow base, mids or highs, in fact all spectrums of your music; giving greater pronouncement to individual rhythms and giving you a complete and dynamic show.
Nowhere to hide
Control up to 20 fixtures, each with up to 48 channels – with a maximum of 512 channels! (This will shortly be increased to an amazing 40 fixtures through a simple software update). This level of total light command empowers you to influence your audience far beyond the boundaries of the dance floor. And programming is a breeze with a joystick for manual pan and tilt guidance.
Custom buttons
Functions such as strobe, smoke, mirror ball activation and more can be allocated to each of four programmable buttons for simplified effects juggling.
Fade to Flash
Assign effects, scenes or dimmers to any of six faders and flash buttons and access them live during playback. You can also set the Grand Master Fader for overall light intensity and Pitch Fader to get pulses racing; speeding your show by up to fives times when the moment dictates.
Data Dispatch
Connect your PC directly to Xciter via the USB connection to update fixture libraries, to back up, edit, export and import shows.
Streamline
The Xciter’s excellence is not exclusive to within. Martin has matched ingenuity and functionality with grace and aesthetics. Cool blue LCD displays lend both kudos and an easy navigation for Xciter’s show menu, dialogue and fader label screens. A jog wheel also delivers a friendly scrolling function through fader pages while a joystick simplifies the manual pan and tilt control.
Specificatii tehnice
20 fixtures, (Soon to be 40), with maximum of 48 channels dimmers (Totally max. 512 channels)
Add Pan/Tilt shape effects with timing effects
Add any effect to a single channel including timing effects
Up to 10 manual override scenes during playback on faders
Pitch more tasteless; gives increase or decrease to show speed by up to 5 times.
Freeze button
Master more tasteless to adjust general light intensity
4 Programmable custom buttons.
Assign different spectrums of the music as a trigger for any parameter of the fixture (s).
Export, backup or import shows via USB to PC.
Physical:
Dimensions (length x width x height): 483 x 265 x 120 mms (19 x 10.4 x 4.7 in.)
Weight: 4.65 kg (10.3 lbs)
Power supply:
Operating range: 90-250V AC, 50-60Hz
Maximum power: 15 W
Processing power:
High-final Infineon micro controller at 40 MHz
2 mb of almost working memory
8 mb of high endurance storage memory
Separate processor for IO handling
Interfaces:
1 x DMX paints in (5-pin XLR)
1 x DMX out (3 and 5-pin XLR female)
1 x MIDI in (DIN5 female)
1 x MIDI out (DIN5 female)
1 x MIDI through (DIN5 female)
1 x USB slave port (USB B)
1 x audio in (5 mms mono jack)
1 x internal microphone
1 x IIC expansion port (DIN5 female)
Controls:
Softly power button with 2 sec switch out of vision security
Master more tasteless to adjust general light intensity
Master flash button
Black out button
Pitch more tasteless with center click to adjust sequence timing during playback
Freeze button
6 faders and flash buttons for parameter control and direct access scenes during playback
Programmable smoke, strobe, specially 1 and specially 2 buttons
40 x 2 character LCD with blue backlight to show more tasteless labels (parameters and values)
Jog wheel to scroll through more tasteless pages
20 x 4 character LCD with blue backlight to show menus and dialogues
8 softly buttons to select items on the display
Jog wheel to scroll through lists and input data
ESC and ENTER buttons for menu and dialogue control
Dim button for direct access to dimmer channels
Fixed button to control fixtures
Cue button to launch single cues
Cue list button to activate cue lists
8 page buttons to select cue pages and fixture groups
20 general purpose buttons to select cues, select fixtures and input data
Shift key to access secondary functions of certain buttons
Previous and next buttons used for single stepping, inputting data, navigation
Joystick for pan / tilt control with built-in button to toggle coarse / fine
Pan exclude button
Tilt exclude button
Home button to send all selected fixture to their home position
Softly wrist pad for comfortable control
USB A connector for desk light
B USB connector for PC link
Programming and playback facilities:
40 fixtures of maximum 48 channels – (totally max. 512 physical channels)
20 dimmers of maximum 48 channels – (totally max. 512 physical channels)
Built-in Martin fixture library (other libraries can be updated via USB)
Library editor to create your own fixture definitions
Up to 160 cues (1 background scene 4 sequences can run simultaneously by cue)
Up to 160 cue lists (automated shows with go, chase and wait functionality)
Up to 160 presets on all channels
16 bits possible on all channels
Effect generator with adjustable speed, swing and delay
Effect macro to recall complex effects instantly (several effect macros factory-loaded)
Relative and absolute control possible over all channels
16 bits fan control on all channels to create spread-outs
Up to 6 sequences can be cross faded with cues during playback
Sequence trigger modes: internal clock, manual, audio (4 band, adjustable levels), BPM (with record mode)
Sequence options: forward, backward, bounce, random, one-shot freeze, one-shot release
Autostart of automated shows with auto lamp-on feature
Export / import show or library via USB left to PC
