Detalii
The Electro Voice Sx300WE is the world"s best lightweight, high-power speaker system with 300-watt continuous - and 1,200-watt peak - power handling. It delivers over 125 dB continuous with 131 dB peaks (one-watt /one-meter) at full power. Its 65 degree x 65 degree, Constant Directivity horn allows for vertical or horizontal use with identical coverage.
The Sx300E presents better pattern control and projection than typical 90 degree horns, and features proven and reliable EV components, including a DL12BFH cast-frame, 12-inch woofer and DH2010a pure titanium compression driver. With Ring-Mode Decoupling, it delivers accurate vocals, instruments and mids. The Sx300E"s rugged, durable, polypropylene enclosure is light, strong, and available in either black or white. Its built-in stand-mount and inserts on the enclosure allow the system to be safely suspended and arrayed using a wide range of optional, cost-effective hardware. The Sx300 can also be used as a floor monitor with F200 attachment, and parallel, Neutrik Speakon input connectors for safe, loss-free connections.
Specificatii tehnice
Features:
Ring-Mode Decoupling (RMDTM) for increased intelligibility
Colour: white
Lightweight, durable polymer enclosure with intregal handles and stand mount
EV DL12-BFH 12-inch woofer and DH2010A compression driver for great sound and reliable performance
Constant-directivity 65 x 65 high-frequency horn
Dual Neutrik Speakon high-current connectors
Molded-in attatchment points for secure suspension
Technical Data:
Frequency Response (-10dB): 50 - 20000 Hz
Sensitivity 1W/1m: 99 dB
Max. SPL / 1m (calc): 131 dB
Coverage (nominal -6dB) H: 65
Coverage (nominal -6dB) V: 65
System Power Handling (continuous/program/peak): 300/600/1200 Watts
LF Transducer: DL12BFH
HF Transducer: DH2010
Crossover Frequency: 1500 Hz
Nominal Impedance (Passive): 8 Ohms
Minimum Impedance: 6 Ohms
Directivity Index: 11.1 dB
Flying: Yes
Input Connections: Four-pin Speakon (2)
Outdoor: No
Chassis Size: 12 inches
Internal Crossover: Yes
Speaker Type: Fullrange, Mid-High, Two-Way
Weight Net: 14.5 kg ( 31.97 lbs )
Dimensions (HxWxD): 586 x 429 x 312 mm (23.07" x 16.89" x 12.28")
