Detalii
Compact two-way 12-inch system with 300 watts continuous, 1,200 watts peak power handling. Delivers over 125 dB continuous, 131 dB peak at full power (at 1 m) | Molded-in 65� x 65� constant-directivity high-frequency horn allows vertical or horizontal orientation without changing coverage pattern | Black polypropylene enclosure is lightweight and extremely durable | Parallel Neutrik Speakon� high-current connectors | Full-faced, black powder-coated stainless steel grille, backed by foam weather shield, gives smooth appearance and a high degree of weather resistance. Safe for outdoor use. | Molded-in suspension points accommodate optional Mb100 forged eyebolts, Mb200 wall/ceiling brackets or Mb300 horizontal array kits for safe, cost-effective overhead suspension | Ring-Mode Decoupling (RMD) delivers pure, detailed vocals and accurate, smooth mids and instruments
Specificatii tehnice
Frequency Response (-10dB) 50 - 20000 Hz
Sensitivity 1W/1m 99 dB
Max. SPL / 1m (calc); full space 131 dB
Coverage (nominal -6dB) H 65
Coverage (nominal -6dB) V 65
System Power Handling (continuous/program/peak) 300/600/1200 Watts
LF Transducer DL12BFH
HF Transducer DH2010
Crossover Frequency 1500 Hz
Nominal Impedance (Passive) 8 Ohms
Minimum Impedance 6 Ohms
Directivity Index 11.1 dB
Flying Yes
Input Connections Four-pin Speakon (2)
Outdoor Yes
Chassis Size 12 inches
Internal Crossover Yes
Speaker Type Fullrange, Mid-High, Two-Way
Weight Net 14.5 kg ( 31.97 lbs )
Dimensions (HxWxD) 586 x 429 x 312 mm
