The Electro Voice Sx250 is a 15-inch, two-way speaker system with 350-watt continuous and 1,400-watt peak power handling. It has a 80 degree x 55 degree Constant Directivity horn to provide better projection capabilities than typical 90 degree horns. The Sx250 features EV DL15BFH cast-frame woofer, a high-performance, and a DH2010a pure titanium compression driver. With Ring-Mode Decoupling, the speaker system delivers rich, smooth vocals and accurate, detailed mids. Its dual, Neutrik Speakon input connectors ensure loss-free signal transfer, and comes with a built-in, metal stand-mount. The Sx250"s enclosure is built of 18 mm plywood and is finished in black Futura, a baked-on polyurethane finish that is very rugged. The system can be safely suspended using the optional SK-1 hardware kit.
Specificatii tehnice
Features:
Small-format 15-inch two-way full-range speaker system
18 mm plywood enclosure
EVCoatTM finish is rugged and weatherresistant
DH2010A pure titanium compression driver coupled to an 80o x 55o Constant-directivity horn
EV 15-inch cast-frame woofer
50 Hz usable bass response
Metal stand mount built in
Suspendable using optional SK-1 kit
Color Black
Technical Data:
Frequency Response (-10dB) 50 - 20000 Hz
Recommended High-Pass Frequency 45 Hz
Sensitivity 1W/1m 99 dB
Max. SPL / 1m (calc) 130 dB
Coverage (nominal -6dB) H 80
Coverage (nominal -6dB) V 55
Rotatable Horn No
System Power Handling (continuous/program/peak) 350/700/1400 Watts
Crossover Frequency 1600 Hz
Nominal Impedance (Passive) 8 Ohms
Minimum Impedance 5.2 Ohms
Directivity Index 11.6 dB
Flying Optional
Input Connections Four-pin Speakon (2)
Outdoor No
Chassis Size 15 inches
Internal Crossover Yes
Speaker Type Fullrange, Mid-High, Two-Way, Wedges
Weight Net 22.7 kg ( 50.04 lbs )
Dimensions (HxWxD) 625 x 431 x 330 mm (24.61" x 16.97" x 12.99")
