Electro Voice - Monitor TX 1152 FM

---

   TX1152FM is a 15-inch two-way vertical floor monitor with an undeniable combination of functional good looks, compact design and engineering breakthroughs, Tour X FM will redefine the world of stage monitors for years to come. The TX1152FM advances the legacy of the globally accepted EV FM series and advances it with a healthy dose of innovative Electro-Voice� engineering.

---

   The split baffle design with patent-pending SST (Signal Synchronized Transducers) technology is the most innovation of the Tour X FM models. A split baffle creates two very important benefits: moving the acoustic origins of the compression driver and woofer close together, and the split in the baffle becomes the port, allowing for a much more compact enclosure. The result of this design is �signal synchronized� with nearly perfect phase summation. With a unique Backbone grille, Tour X FM models not only look great, but also provide greater strength and damage resistance than ordinary grille block designs. Proprietary, ergonomically correct handles and angled input panels make the Tour X FM models easy to transport and set up in critical stage monitoring additions.

---

   Features:

---



---

    55 Vertical Floor Monitor with Signal Synchronized TransducersTM

---

    100 dB Sensitivity, 133 dB Maximum SPL

---

    DH3 1.25 (32mm) Diaphragm, 1 (25mm) Exit Pure Titanium Compression Driver

---

    SMX2151 15 (381mm) LF Transducer with Fully Symmetric Drive

---

    Integrated Crossover with Steep 24 dB/Octave Slopes and HF Protection

---

    90 x 50 Coverage Pattern

---

    500W Continuous (2000W Peak) Power Handling

---



---

   Technical Data:

---



---

    Frequency Response (-3dB) 65 - 20000 Hz

---

    Frequency Response (-10dB) 45 - 20000 Hz

---

    Recommended High-Pass Frequency 45 Hz

---

    Sensitivity 1W/1m 100 dB

---

    Max. SPL / 1m (calc) 133 dB

---

    Coverage (nominal -6dB) H 90

---

    Coverage (nominal -6dB) V 50

---

    Rotatable Horn No

---

    System Power Handling (continuous/program/peak) 500/1000/2000 Watts

---

    LF Transducer SMX2151

---

    HF Transducer DH3

---

    Crossover Frequency 1750 Hz

---

    Nominal Impedance (Passive) 8 Ohms

---

    Minimum Impedance 6.2 Ohms

---

    Enclosure Material Plywood and MDF with EVCOAT

---

    Color Black

---

    Flying No

---

    Input Connections Parallel Neutrik NL4

---

    Internal Crossover Yes

---

    Speaker Type Fullrange

---

    Weight Net 23.5 kg ( 51.81 lbs )

---

    Dimensions (HxWxD) 475 x 439 x 655 mm

---

   (18.7" x 17.28" x 25.79")
