The EVID 3.2 is a very compact full-range loudspeaker ideal for indoor and outdoor applications requiring high-quality sound. Its shape and size make it nearly invisible for use in
background/foreground music systems for restaurants, bars, patios, retail, and other applications The 3.2�s three-dimensional elliptic baffle symmetrically locates the .75� Ti direct radiator high-frequency element in front of and between the 3.5� low-frequency drivers. The
careful shaping, location, and 10� splaying of the LF units provide coverage control by the resulting line array. Lobing is controlled by physically �shadowing� the LF transducers from
each other over the bandwidth where they would normally exhibit interference. EVID�s mounting system provides greater range of aiming angles in both horizontal and vertical planes than other types. The curved grille features designed-in weather resistance and a hidden leash for safety. All models are available in black or white, and can easily be
painted to match the d�cor. Transformer versions are also available for constant voltage systems.
Specificatii tehnice
Features:
Line-array enhanced coverage control
Organic, unobtrusive shape
Strong-Arm-MountTM for easy, flexible aiming
Full-bandwidth overload protection
Weather resistant - Conforms to Mil Spec 810 and IEC 529 IP 34
Dual LF transducers for extended bass and greater power handling and output
Ti direct-radiator HF transducer, Neodymium structure
High sensitivity
Magnetically shielded
Zinc-plated grilles
Transformer Versions
Technical Data:
Frequency Response (-10dB) 85 - 20000 Hz
Sensitivity 1W/1m 87 dB
Max. SPL / 1m (calc); full space 112 dB
Coverage (nominal -6dB) H 140
Coverage (nominal -6dB) V 100
Nominal Impedance (Passive) 8 Ohms
Minimum Impedance 6 Ohms
Input Connections Spring Terminal
Transformer Taps (Transformer Version Only) 70V:5W, 100V:10W
Chassis Size 3.5 inches
Weight Net 1.5 kg ( 3.31 lbs )
Dimensions (HxWxD) 234 x 127 x 165 mm, (9.21" x 5" x 6.5")
