The Electro-Voice � EVID 12.1 is a subwoofer system designed to complement the EVIDTM line of full-range loudspeakers. The 12.1 is ideal for supplementing the bass response of any EVIDTM model in an indoor application. It is particularly useful in sports bars, dance floors, retail environments, health clubs, restaraunts, etc. The 12.1 adds the extra dimension of a powerful low end where foreground music is desired. The 12.1�s slot-loaded design allows for flexible mounting and placement while delivering the smoothest bass response possible. The 12-inch high-excursion woofer, with its dual voicecoil design, enables both the L/R channels to feed into the speaker while at the same time providing crossed-over outputs for up to 4 satellite speakers. If desired, the 12.1 can be powered separately for an even more powerful presence. The 12.1 features reinforced steel-fastener construction that allows for a
variety of mounting configurations. The 12.1 is available in black or white, and can easily be painted to match the decor. All mounting hardware is included.
Specificatii tehnice
Features:
12-inch High-Excursion LF Transducer
Trapezoidal Shape allows for flexible placement
Secure Reinforced Cabinet Construction with Mounting Hardware included
Extremely High Power Handling
High Sensitivity
Paintable Enclosure available in Black or White Finishes
Dual Voice Coil Design accommodates both Stereo Channels
Crossed-Over Pass-Thru Connections for up to 4 Satellite Speakers
Technical Data:
Frequency Response (-10dB) 40 - 140 Hz
Sensitivity 1W/1m 100 dB
Max. SPL / 1m (calc); full space 125 dB
System Power Handling (continuous/program/peak) 175/350/700 Watts
Nominal Impedance (Passive) 6 Ohms
Minimum Impedance 6 Ohms
Flying No
Input Connections Spring Terminal
Internal Crossover Yes
Chassis Size 12 inches
Weight Net 18.1 kg ( 39.9 lbs )
Dimensions (HxWxD) 412 x 584 x 305 mm, (16.22" x 22.99" x 12.01")
