Detalii
- 24 configurable faders
- 2 DMX universes
- Additional artNET output
- DMX input
- VGA monitor output option
- Built-in FX generator
- LCD step-by-step instruction
DMX512 console allows for control of conventional lights, moving lights and LED’s.
Three in One Control!
Six operation modes; Single Scene, Two Scene, Sub Master, Moving Light, LED and Memory playback modes.
1152 recordable scenes (24 pages x 48 scenes) in sub master mode for conventional lights.
12 built in FX include movement for ML’s and color chases for LED’s.
LCD display offers detailed information.
Specificatii tehnice
- DMX512 console allows for control of conventional lights, moving lights and LED's.
- Six operation modes; Single Scene, Two Scene, Sub Master Moving Light, LED and Memory playback modes.
- 1152 recordable scenes (24 pages x 48 scenes) in sub master mode for conventional lights.
- 12 built in FX include movement for ML's and color chases for LED's.
- LCD display offers detailed information.
- 24 faders to control conventional, moving light and LED fixture channels
- Control 8 ML fixtures up to 40 channels each. 20 playbacks x 99 steps in Moving Light mode
- Control 8 LED (RGBA) fixtures. 20 playbacks x 99 steps in LED mode Memory playback mode allows for a combination of Sub Master, LED playback and Moving Light playback
- Back lit buttons (by RGB LED's) change color depending on their state
- Grand Master fader for total output control
- A & B fader's for two scene operation
- USB Input for uploading and downloading data
- ArtNET for faster communication with compatible devices
- 3 pin XLR DMX Input to connect external console
- Two sets of 3 & 5 pin DMX Outputs
- On/Off Power Switch
- 9-12VDC 2A power supply (Included)
- 800x600 VGA monitor output (optional)
- Dimensions: 70x482x264mm (HxWxL)
- Weight: 4,36 kg
