Detalii
Specificatii tehnice
- Universal, single channel, LED driver
- 10 position dipswitch for Stand Alone presets and DMX address
- USITT DMX512 (1990) compatible
- DMX and Stand Alone operation modes
- Power Output: Dual terminal type, 12- 24VDC outputs, 6 Amps Max.
- DMX Output Operation Modes: One DMX channel
- Power Input: 12- 24VDC, 6 Amps Max.
- DMX Input: 3-Pin terminal type connector
- DMX Output: 3- Pin terminal type connector
- Dimensions: 2.64” x 1 .57 x .59” (67mm x 40mm x 15mm)
- Weight: 1 lbs. (150g)
- Operation Temperature: -10 degC to +50 degC
- Storage Temperature: - 20 degC to +70 degC
- CE Certified
