The last three decades have seen over 50.000 DJs worldwide performing their music with a MAC mixer, a true legend which the new MACv Series contributes to perpetuate, as it upgrades its features in accordance to the latest technological advances.
Today�s discotheques, pubs, clubs, mobile systems and everywhere a pristine audio processing is required, can keep enjoying the legendary MAC Series, the most advanced, toughest and reliable mixer around.
Specificatii tehnice
Features:
- Independent input sensibility control for each channel with -20 dB adjustment range, Gain.
- Independent 3 band tone controls for each channel with -20dB to +10 dB adjustment range on channels 1 and 2 and from Cut to +10 on all other channels.
- Pre-Listening function with headphones volume control and monitoring possibility through the CUE output (with dedicated volume control) and an external amplifier.
- Phantom power supply for condenser microphone, with individual internal ON/OFF settings.
- VU-Meter: Displays the level of any channel signal before the fader (PFL), main programme mix (MIX) or AFL output.
- Independent Balance for each channel and L+R switch for summing both stereo signals.
- Inputs: 2 Phono, 3 High Line (high level line for compact discs, DAT, MP3 players), 2 Low Line, Aux In and Mix; plus 1 input ready for balanced microphones (XLR3).
- Outputs: 2 Out Outputs with independent volume control (Out 1 balanced), two Rec outputs and one Cue output.
- Ecler Crossfader: Modular, removable fader with VCA circuit. Channels 1 and 3 can be assigned via the XFA switch to the A side of the crossfader. An analogue XFB switch at the even channels 2 and 4 assign these signals to side B of the crossfader. In any case, when these switches are not activated, the signals are directly assigned to the main Mix bus.
Inputs Sensitivity nom/Impedance LINE (LOW) -10dBV/50KW
Line (HIGH) 0dBV/50kW
Phono -40dBV/50kW
Micro (BAL) -50dBV/>1kW
Micro ATT.(BAL) -30dBV/>1kW
Mix 0dBV/7kW
Outputs Level/Minimum Load OUT 2 0(+6)dBV 1(2)V */2.2kW
Out 1 (BAL) 0(+6)dBV 1(2)V */600W
Cue 0dBV/10kW
Rec 0dBV/10kW
Headphones 230mW/400W
Frequency Response Line 15Hz-35kHz -1dB
Micro bal 20Hz-25kHz -1dB
Phono RIAA -0.5dB
THD+N Line <0.03%
Micro <0.09%
Phono <0.2%
CMRR Micro >70dB @ 1kHz
Signal Noise Ratio LINE >95dB
Micro >85dB
Phono >80dB
Gain control all inputs GAIN -20dB
Tone control channel 1 and 2 Bass -20/+10dB
Mid -20/+10dB
Treble -20/+10dB
Tone control channel 3 and 4 Bass -30/+10dB
Mid -25/+10dB
Treble -30/+10dB
Kill Filters channel 3 and 4 LOW 200Hz
(cut frequency at -6dB) Mid 6.5kHz & 200Hz
Slope 12dB/oct in all the cases HIGH 6.5kHz
Phantom voltage +18VDC/5mA max.
Mains 90-264VCA 47-63Hz
Power consumption 26VA
Dimensions Panel 482.6 x 266 x 99 mm
Weight 3.7 kg.
(*)Internally selectable
